9
Device layout (WWAN / WiFi)
Proximity
Light sensor
Speaker
(WWAN)
► WWAN:
SIM card /
Memory
card tray
► WiFi:
Memory
card tray
Keyboard
dock port
Recents key
Home key
(Fingerprint
recognition
sensor
only with
Tab-Ex 03 D2)
Front camera
Volume key
Side key
(Power/Bixby)
Active key
Touchscreen
Back key
Multipurpose
jack
(USB Type- C)
