2017-09
8
Functional Safety HiD2022*, KFD2-STC5-(Ex)*, KFD2-STV5-(Ex)*
Product Description
KFD2-STC5-1, KFD2-STC5-2
This signal conditioner provides the galvanic isolation between field circuits and
control circuits.
The device supplies 2-wire and 3-wire SMART transmitters, and can also be used
with 2-wire SMART current sources.
It transfers the analog input signal as an isolated current value.
Digital signals may be superimposed on the input signal on the field side or on the
control side and are transferred bi-directionally.
The device provides a sink mode or a source mode output on the control side
terminals.
The device has an internal resistor. Use this resistor if the HART communication
resistance in the control circuit is too low.
Test sockets for the connection of HART communicators are integrated into the
terminals of the device.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
KFD2-STC5-1.2O
This signal conditioner provides the galvanic isolation between field circuits and
control circuits.
The device supplies 2-wire and 3-wire SMART transmitters, and can also be used
with 2-wire SMART current sources.
It transfers the analog input signal to the control side as two isolated output
signals.
Digital signals may be superimposed on the input signal on the field side or on the
control side and are transferred bi-directionally.
The device provides a sink mode or a source mode output on the control side
terminals.
The device has an internal resistor. Use this resistor if the HART communication
resistance in the control circuit is too low.
Test sockets for the connection of HART communicators are integrated into the
terminals of the device.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
