PHS2000
V. 02 – 06/04/2020 5 ©Velleman nv
3. General Guidelines
• Refer to the Velleman
®
Service and Quality Warranty on the last pages of this manual.
• All modifications of the device are forbidden for safety reasons. Damage caused by user
modifications to the device is not covered by the warranty.
• Only use the device for its intended purpose. Using the device in an unauthorised way will
void the warranty.
• Damage caused by disregard of certain guidelines in this manual is not covered by the
warranty and the dealer will not accept responsibility for any ensuing defects or problems.
• Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary,
incidental or indirect) – of any nature (financial, physical…) arising from the possession,
use or failure of this product.
• Keep this manual for future reference.
4. Overview
Refer to the illustrations on page 2 of this manual.
heating element connection
5. Assembly
Insert the lower post into the base and fix with four M6x30 screws. Also, insert the clamp into
the lower post.
Mount the middle post onto the lower post and fix with three M5x6 screws.
