Read all safety warnings before operation.
WARNING!
Failure to obey these warnings may result in loss of load, damage to engine crane, and/or
engine crane failure resulting in personal injury or property damage.
WARNING!
Do not overload engine crane beyond rated capacity of each specified boom position.
Overloading can cause damage to or failure of the crane.
Always use crane on hard, level surface capable of sustaining the load. Use of crane on other
than hard level surfaces can result in crane instability and possible loss of load.
Boom and load must be in lowest possible position before moving. Move load slowly and
smoothly to avoid uncontrolled swinging and possible loss of load.
Be sure all personnel are clear of the load before lowering.
FRONT LEGS MUST ALWAYS BE LOCKED IN DOWN
POSITION BEFORE APPLYING LOAD AND/OR RAISING BOOM
(See Figure 2, page 5).
BOOM MUST BE IN FULLY LOWERED POSITION BEFORE
RAISING LEGS. LEGS MUST NEVER BE RAISED WHEN
CRANE IS CARRYING LOAD. LEGS MUST BE LOCKED IN
PLACE WHEN RAISED (See Figure 3, page 5).
NEVER WORK UNDER LOAD.
SPECIFICATIONS
Max. Capacity: .............. 4,000 lbs.
Base length: ................... 72-3/8 in.
Base Width: .................... 40-1/4 in.
Max. Height: (1/2 ton) ..... 95-1/4 in.
Max. Height: (2 ton) ........ 82-1/2 in.
Specifications are subject to change
without notice
IMPORTANT SAFETY INFORMATION
3
