404EA-22T Turbocharged Engine
Illustration 35 g06697297
Typical example
(1) Coolant temperature sensor/switch (2) Inlet manifold temperature and pressure
sensor (if equipped)
M0132847 39
Operation Section
Sensors and Electrical Components
