P9
Option D
For cable interference or inset holes, use spacers [M-H] and [M-I] to create
extra space between the TV and TV brackets.
The spacers must be used with washers [M-G] to stop spacers from falling down.
Spacers may be necessary for 2 holes ONLY.
The spacers must be used with washers
[
M-G
]
to stop spacers from falling down.
Option C (For TV with A “Bump”)
M-B/M-
D/M-E
M-H/M-I
M-G
M-F
3
Note: Keep
the arrow up
M-F
M-B/M-D/M-E
M-H/M-I
M-G
M-F
M-A/M-C
3
M-G
M-G
Alternate Spacer
Setups
Alternate Spacer
Setups
