P8
Option B (For Round Back TV)
M-F
M-I(If needed)
M-G
M-A/M-C
M-F
M-B/M-D/M-E
M-H/M-I
M-G
Note: Keep
the arrow up
Note: Keep
the arrow up
Option A (For Flat Back TV)
M-G
M-G
The spacers must be used with washers
[
M-G
]
to stop spacers from falling down.
Alternate Spacer
Setups
The spacers must be used with washers
[M-G]
to stop spacers from falling down.
To Next Page
