PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
16 | perlick.com/residential
INSTALLATION INSTRUCTIONS
6) If you would like to reverse the door hinges, do the
following:
a) Contact your local distributor to purchase Perlick
70084. The kit contains “hinge (A)-le.”
b) Remove the 2 bolts securing the top panel, then li
it o (See Fig. 4).
Hinge (A)-Le
Bracket
Screw
Top Brace
Gasket Notch
Screw
Hinge (A)-Right
Not Needed
Fig. 4
Bolts
Top Panel
d) Remove hinge (B) from the right side of the
appliance and the 2 ller screws from the le side.
Aach the 2 ller screws to the right side and aach
hinge (B) to the le side (See Fig. 6).
e) Rotate the top panel 180° from its previous posion.
This brings the notch that was previously in the
right rear to the le front (See Fig. 7). Hook the rear
part of the panel on the body, then secure the front
with the 2 bolts removed in step 6a.
f) Remove hinge (C1) from the top right part of the
door, ip it and reaach to the boom le. Remove
hinge (C2) from the boom right part of the door,
ip it and reaach to the top le (See Fig. 8).
Proceed to step 7.
Fig. 6
Hinge (B)
Filler
Screws
Screws
c) Remove hinge (A)-right and the bracket from the
right side of the appliance. Set aside hinge (A)-right;
it is not needed. Remove the top brace from the le
side. Fasten hinge (A)-le and the bracket to the le
side and the top brace to the right side (See Fig. 5).
Note: When on the proper side, the gasket notch for hinge (A) is
to the inside.
Fig. 3
Hinge Stop Pin
Hinge (B)
Hinge (A)
5) While maintaining a hold on the door, remove the
hinge stop pin from hinge (B). Pull out the boom of
the door slightly and gently remove the door from
hinge (A) (See Fig. 3). If you are leaving the door right
hinged, skip to step 7. If you would like to reverse the
door hinges, proceed to step 6.
Fig. 5
