PERLICK RESIDENTIAL UNDERCOUNTER REFRIGERATION USE & CARE GUIDE
8 | perlick.com/residential

ThefollowingtabledescribesLEDFunons
NOTE: When switched on, the device performs a Lamp Test;
the display and LEDs will ash for several seconds to check that
they all funcon correctly.
DIAL TEMPERATURE CONTROL

(Excludes ADA Freezer - HA24F models use digital controller
found on page 5)
TOUCH-SCREEN CONTROL OPERATION - FREEZER MODELS
Useastraightslotscrewdrivertoadjustthedialtemperature
control.Thecontrolislocatedatthetoprearpanelofthe
cabinet.Approximatetemperaturerangesareasfollows:
Adjustthetemperatureasfollows:

Turntheadjusngscrewclockwise(totheright).

Turntheadjusngscrewcounterclockwise(tothele).

Turntheadjusngscrewcompletelycounterclockwisetothe
OFFposionunlaclickisheard.
NOTE: The condenser fan motor turns o with the compressor.
ADA-Compliant Series
Model Temp Range
HA24RB 33° - 42° F
HA24BB 35° - 48° F
HA24WB 45° - 65° F
C-Series Models
Model Temp Range
HC24RB 33° - 42° F
HC24BB 33° - 48° F
HC24WB 45° - 65° F
Defrost LED
Permanently on: defrost active
Flashing: manual defrost active
O: otherwise
Alarm LED
Permanently on: alarm active
Flashing: alarm acknowledged
O: otherwise
Evaporator LED
Permanently on: fans active
O: otherwise
Compressor LED
Permanently on: compressor active
Flashing: a delay, a protection or a
locked start-up
O: otherwise
Aux LED
Permanently on: Aux output
active
O: otherwise
°C LED
Permanently on: display the
temperature
O: otherwise
C
O
O
L
E
R
OFF
1
2
3
4
5
6
COLD
Figure 3. Dial Temperature Controller
