Settings and adjustmentUser Manual VS
Control panel (rotating panel holder)
The location of the control panel can be adjusted lengthwise to find the optimum
driving position. It is also possible to adjust the angle of the panel sideways,
which facilitates getting in and out.
Length adjustment
1. Undo the screw on the underside of the armrest and adjust the panel to
the required position.
2. Tighten the screw.
Adjustment of friction joint
Using the knob on the friction joint, it is possible to adjust how easily or stiffly the
panel can be angled laterally.
Control panel with rotating panel holder
Screw
Knob
Friction joint knobLength adjustment screw
