Lower
locating
lever
Control
lever
Eccentric,
lower
locating
lever
Turntable
bearing
bracket
Loosen
the
retaining
screws
(64
and
66)
and
move
the
bearing
bracket
as
required
to
ensure
easy
engagement
of
the
turntable
pinion.
Control
lever
cannot
be
moved
to
LIFT
Cause:
Clearance
between
the
lower
locating
lever
(151)
and
the
bent
portion
of
the
control
lever bottom
assembly
(175)
too
small
Remedy:
Adjust
the
eccentric
(A>
at
the
lower
locating
lever,
Position
of
tower
locating
lever
The
clearance
between
the
curved
extension
of
the
lower
locating
lever
(151)
and
the
control
lever
bottom
assembly
can
be
adjusted
by
means
of
the
eccentric
(A)
at
the
left
of
the
pivot.
For
this
pur
pose,
the
control
lever
must
be
in
the
1st
lift
posi
tion.
The
clearance
should
be
between
20
and
40
mils
(0.5
to
1
mm).
Adjusting
tool:
Screwdriver
Switch
operating
lever
In
the
normal
position
of
the
control
cam,
the
lever
(K)
must
clear
the
ON/OFF
switch
about
20
mils
(0.5
mm).
When
the
control
lever
is
moved
to
“START”
or
“LIFT”,
the
red
lever
of
the
ON/OFF
switch
must
be
supported
on
the
backstop.
If
the
starting
lever
(197) is
engaged
with
the
stop
pawl,
the
switching
roller
(176)
must
clear
the
starting
lever
(197)
8
mils
(0.2
mm)
in
any
position
of
the
control
lever.
Adjusting
tool:
Pliers
Pick-up
arm
has
no
friction
Cause:
Insufficient
spring
contact
(Y)
on
pick-up
arm
locator
segment
Remedy:
Adjust
the
friction
spring
(Y)
Pick-up
arm
friction
The
pick-up
arm
friction
amounts
to
15
to
20
p.
when
the
pick-up
arm
s
rafsed.
Bending
the
spring
supports
(Y)
permits
changing
the
position
of
the
spring
with
respect
to
the
pick
up
arm
locator
segment
(YY).
Care
should be
taken
to
see
that
a
clearance
of
0.571”
(14.5
mm>
exists
between
the
lower
edge
of
the
pick-up
arm
locator
segment
(YY)
and
the
chassis
board.
Adjusting
tools:
Pliers,
Force
gauge
0-30
p.
Operating
noise
heard
during
change
cycle
Cause:
Muting
switch
fails
to
make
contact
properly
Remedy:
Adjust
muting
switch
In
playback
position
of
the
record
player,
the
two
shorting
springs
should
clear
the
cçntact
bars
0.020”
(0.5
mm).
Loosen
the
retaining
screws
of
the
mutng
switch
and
turn
the
muting
switch
until
this
clearance
is
obtained.
Adjusting
tool:
Screwdriver
