Perrot Water Control+ SC - Specific Connection Instructions


TDP072d+e.doc Rev.07.07.2015 Seite‐Page38/64
PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany
Telefon:0049‐7051‐162‐0/Fax:0049‐7051‐162–133
E‐mail:perrot@perrot.de/E‐mailKonstruktion:technik@perrot.de
Connectcontrollerandvalves
 Connectallvalvesandinputs/outputsaccordingtothewiringdiagram.



 Use fieldcableconnectionlugswithsafetysnagfeatureincludedinthepackageforall
cables.
 Theoutputcurrentmustnotexceed150mA/coil

Mastervalvesandpumprelays



 Theremustbeatleasta5mdistancebetweenthepumprelayandthecontroller,thus
avoidingandprotectingthedevicefromvoltagepeaks.
Connectrainsensor
 Both,normallyopencontactsornormallyclosedcontactscanbeusedasarainsensor.
 Connectrainsensorasperwiringdiagram.
 Turnthemaindialto“Setup” andsetappropriatetypeofrainsensor(openerorcloser).

Connectkeyswitchforexternalprogramstart(Order‐no.:SB49165)
 Connectkeyswitchasperwiringdiagram.
 Werecommendtouse:
 Jungkeyswitch833.18W;WG800IP44contact(opener/closer)
and
 JungprofilecylinderforkeyswitchUP3key(closer),3051938Jung28
(Granzoworderno.)

Turnthemaindialto“Setup”andselectkeyswitch(page16).


Connectshorttimeclock(externalswitch)
 Valveswithshorttimeoperationmaybeactivateddirectlyonsite,usingthepermanent
24VACcontact(seewiringdiagram).Thiscircuitiscommonlyusedontenniscourtsin
ordertoeliminatedustbyshort‐termirrigation.

Note: Themastervalvewillnotstartwhenactivatingthevalvesbymeansof
ashorttimeclock.Thiswillrequirespecialcabling.
Pleasecontactthemanufacturer.
