10 PFAFF
Inserting the needle
Switch off the machine.
Only use needle system 134-35.
Raise and disengage roller presser (see page 9).
Loosen needle retaining screw 1 and push needle
right in (the long groove must face to the left).
Tighten needle retaining screw 1 and re-engage the
roller presser.
1
Fig.8
Fig. 7
1
Winding the bobbin thread
Thread the bobbin thread as shown in fig. 8.
Thread tension (knurled screw 1).
