Pfaff 3834-3/11 - Sewing Machine Operation Controls; Switching Machine On and Off; Sewing Machine Pedal Functions

14 PFAFF
Fig. 18
Switching the machine on / off
0
1
2
3
Fig. 19
Pedal functions
0 =inoperative position
1 =sewing
2 =to raise roller presser
3 =to trim sewing threads and to raise roller
presser
on
off
