7.1.1 SHE oil fixtures with oil lubrication
Fitting
position
M1A
M1B
M2A
M2B
M3A
M3B
M4A
M4B
M5A
M5B
M6A
M6B
Pos 2
Pos 3
Pos 4
/
Pos 5
Pos 6
7.2 Fitting positions HSE
Version A Version B
7.2.1 HSE oil fixtures
Mount
ing
position
M1A
M1B
M2A
M2B
M3A
M3B
M4A
M4B
M6A
M6B
Pos 1
Pos 2
Pos 3
Pos 4
/
Pos 5
/
Oil sight glass or lock
screw
Fill screw/
venting
Drain screw
Pressure bleed plug
(e.g. ATEX)
1 Bleed plug
2 Venting pin
( pull at initial operation)
3 Oil level
Tighten the venting screws always to the highest position.
