REMOVE EXTERNAL PANELS
Loosen the 2 thumb screws of the top
panel in the rear. Slide the top panel to
the rear to remove it.
Remove the screw on the top and slide
the right panel upwards to remove it.
Optionally, remove the back door by
sliding it upwards when it is in open
position.
REMOVE TOP PANEL REMOVE RIGHT SIDE PANEL REMOVE REAR DOOR
04 05 06
1.
1.
2.
1.
2.
1.
2.
THUMB SCREW 2x
LOOSEN
SCREW 1x
REMOVE
2.
