INSTALLING STORAGE
01. Remove the 2.5’’ drive bracket completely.
02. Install 2x 3.5’’ drives with cables routed to
the top
01. Reposition the 2.5’’ drive bracket to the rear
of the motherboard.
02. Install 2x 2.5’’ drives on the door and 2x 2.5’’
drives on the bracket
BOTTOM DOOR STORAGE
The bottom door can be used for
one of the following storage options:
1x 3.5’’ + 4x 2.5’’ | 4x 2.5’’ | 2x 3.5’’
Loosen the thumb screw to open the door.
01
OPEN BOTTOM DOOR
02
INSTALL DRIVES
OPTION A- 1X 3.5’’ + 4X 2.5’’
OPTION C - 2X 3.5’’OPTION B - 4X 2.5’’
to MB
to MB
to MBto PSU to PSU
