Phanteks NV7 User Manual

7
EXPLODED VIEW
PARTS
1 Chassis
2 Front glass panel
3 Right side mesh panel
4 Left glass panel
5 Top panel
6 Bottom fan bracket
7 Side fan bracket
8 Rear door
9 Bottom dust lter
10 Front I/O
11 GPU Support Bracket
12 Motherboard Cover
13 D-RGB Cover
14 Top I/O
15 Rear Mesh Cover
16 Airow Cover
15
04
01
16
13
12
11
08
10
09
06
05
03
07
14
02

Phanteks NV7 Specifications

General

Type	Mid Tower
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Material	Steel, Tempered Glass
Expansion Slots	7
PSU Support	ATX
Maximum CPU Cooler Height	185 mm
Radiator Support - Top	Up to 360 mm
Radiator Support - Side	Up to 360 mm
Radiator Support - Bottom	Up to 360 mm
Radiator Support - Rear	120mm
Fan Support - Rear	1x 120 mm
Drive Bays	2 x 3.5", 4 x 2.5"
Front I/O Ports	2 x USB 3.0, 1 x USB Type-C, Audio In/Out
Fan Support - Top	3x 120 mm
Fan Support - Bottom	3x 120 mm
Maximum GPU Length	450 mm
Fan Support - Side	3 x 120 mm
