3 Basic configuration and structure
3.1 Standard configuration
Base Machine 1
Standard hardness block for B scale 1
Standard hardness block for C scale 3
1/16″Carbideball indenter
1
120°cone diamond indenter
1
Mounting screws for indenter 2
Flat anvil 1
“V ”shape anvil 1
Power supply plug 1
Screwdriver 1
Dust cover 1
3.2 Structure schematic diagram
1- screen and keyboard
2- indenter
3- anvil
4- leadscrew and protecting sleeve
5- handwheel
6- weights( in the tester)
7- switch and power panel
8- printer
Figure 3.1
1
6
3
5
2
4
8
7
