1Overview
TheUTG‐2900isadigitalultrasonicthicknessgauge.Basedonthesame
operatingprinciplesasSONAR,theinstrumentiscapableofmeasuring the
thicknessofvarious materialswithaccuracy ashighas0.001”.Itissuitable
fortestingavarietyofmetallicandnon‐metallicmaterials.

Specifications Model No. UTG-2900
Display type 4.5 -digit LCD w/Back Light
Minimum display unit 0.001”/0.01mm (selectable)
Measuring Range Pulse-Echo: 0.025”-23.0” in steel
Echo-Echo: 0.118” – 2.35”
Accuracy +/- (0.5% thickness + .001”)
Sound velocity range 3280-32805 ft/s (1000-9999m/s)
Upper/Lower Limit Preset Alarm Yes
Scanning Feature Yes, 16 measurements/second
Operating temperature 32-122 degrees F
Frequency 5MHz
Update range 4Hz
Memory 20 Groups (100 files/group)
Output USB
Power supply AA alkaline batteries (2pc)
Battery life Approx. 100 hours (w/backlight off)
Power consumption Working current is less than 3V
Dimensions 5.90” x 2.91” x 1.30” (150 x 74 x 33mm)
Weight 8.6oz (245g)
