KVM100A/200A
2-1
SECTION 2: TECHNICAL SPECIFICATIONS
AC/DC KILOVOLTMETER
KVM100A DIVIDER
KVM200A DIVIDER
HIGH VOLTAGE AC INPUT:
100kVAC maximum
200kVAC maximum
HIGH VOLTAGE DC INPUT:
100kVDC maximum
200kVDC maximum
HIGH VOLTAGE PK INPUT:
100kV PEAK (AC)
200kV PEAK (AC)
DIVIDER CAPACITANCE:
 200 pF
 100 pF
DIVIDER RESISTANCE:
380M
760M
DIVIDER RATIO:
10,000:1
10,000:1
INSTRUMENTATION:
AC / BATTERY POWERED
POWER ADAPTOR:
INPUT: 85-264 VAC, 0.6 A, 47-63 HZ
OUTPUT: +15 VDC, 1.66 A
INPUT JACK:
+15 VDC, 1 AMP
BATTERY PACK:
9.6 Volt Ni-MH 3800 mAh
METER MEASUREMENT
RANGES:
Low Range: 0-20kV
High Range: 0-200kV
ACCURACY:
1% of Reading from 10% -100% of Range
FUNCTION SELECTIONS:
1. AC AVERAGE (Average absolute value, not RMS equivalent)
2. AC RMS (True AC RMS)
3. AC PEAK (Average of the positive and negative peak values)
4. AC PEAK /  2 (“AC PEAK” /  2)
5. DC AVERAGE (Average DC value)
6. DC PEAK (Peak responding including ripple peak)
7. DC RIPPLE (Peak to peak AC ripple on DC voltage / 2)
FREQUENCY RESPONSE:
(SINUSOIDAL WAVEFORM)
AC and Ripple voltage measurement functions in the range of 20-
1000Hz.
SETTLING TIME:
AC Peak, AC Peak / 2,
DC Peak, DC Ripple
AC AVG, AC RMS, DC AVG
--Up to 30 seconds
--Up to 5 seconds
ENVIRONMENTAL
CONDITIONS:
10-40°C, Indoor/Outdoor in fair weather
Humidity <95%, non-condensing
Altitude <3000 ft (1000 meters)
KVM100A
KVM200A
DIMENSIONS:
Inches (mm)
Hight
30.5 (775)
9.5 (241)
9.5 (241)
43.5 (1105)
9.5 (241)
9.5 (241)
Width
Depth
*WEIGHT:
30.5 LBS. 13.8 kg
43 LBS. 19.5 kg
*WEIGHT INCLUDES ALL CABLES
