Philips 107E7 - 5-2.Transistor & Diode Circuit

17” CDT Color Monitor 107E7
24
5-2.Transistor & diode and IC circuit
Location. Description Function
IC101 SAA4849PS CPU
IC601 TDA4863A Vertical Output IC
IC801 NT6812KG-20019 Video PreAmplifier/OSD IC
IC802 LM2476 Video Output IC
IC901 STR-G5643D PWM Combi power MOS IC
IC902 L7805CV DC to DC IC
Q911 IRF634B B+ Transistor
Q403 2SC5929 Horizontal Output Transistor
Q406 IRF630M/S.T Horizontal Size Transistor
Q410 2SC2120-Y Horizontal linearity Transistor
D901~D904 1N5408 PEC Crtical Safety Component
Q426/Q420/Q427 IRF630M/S.T CS adjust Transistor
D919 31DF4/I.R Rectifier DIODE
D922 RG-4S Rectifier DIODE
D923 RG-4S Rectifier DIODE
D925 UF4004 Rectifier DIODE
D408 DMV1500MFD Rectifier DIODE
