17” CDT Color Monitor 107S7
73
2.5.2 Preload video timings
Timing 7. 8.
Resolution 1024 x 768 1280 x 1024
Pixel clock
94.500 MHz 108.000 MHz
H. Frequency 68.677 kHz 63.981 kHz
H. Total
14.561 us 15.630 us
H. Active display
10.836 us 11.852 us
H. Back porch
2.201 us 2.296 us
H. Sync. Width
1.016 us 1.037 us
V. Frequency 84.997 Hz 60.020 Hz
V. Total display
11.765 ms 16.661 ms
V. Active display
11.183 ms 16.005 ms
V. Back porch
0.524 ms 0.594 ms
V. Sync. Width
0.044 ms 0.047 ms
H/V sync
polarity
+ / + + / +
Timing 1. 2. 3.
Resolution 640 x 350 640 x 480 640 x 480
Pixel clock
25.175 MHz 31.500 MHz 40.500 MHz
H. Frequency 31.469 kHz 37.500 kHz 50.628 kHz
H. Total
31.778 us 26.667 us 19.752 us
H. Active display
25.422 us 20.317 us 15.802 us
H. Back porch
1.907 us 3.810 us 1.975 us
H. Sync. Width
3.813 us 2.032 us 1.580 us
V. Frequency 70.087 Hz 75.000 Hz 100.10 Hz
V. Total display
14.268 ms 13.333 ms 9.995 ms
V. Active display
11.122 ms 12.800 ms 9.481 ms
V. Back porch
1.907 ms 0.427 ms 0.435 ms
V. Sync. Width
0.064 ms 0.080 ms 0.059 ms
H/V sync
polarity
+ / - - / - - / -
Timing 4. 5. 6.
Resolution 800 x 600 800 x 600 832 x 624
Pixel clock
40.000 MHz 67.500 MHz 57.280 MHz
H. Frequency 37.879 kHz 63.923 kHz 49.722 kHz
H. Total
26.400 us 15.644 us 20.110 us
H. Active display
20.000 us 11.852 us 14.520 us
H. Back porch
2.200 us 2.370 us 3.910 us
H. Sync. Width
3.200 us 0.948 us 1.117 us
V. Frequency 60.317 Hz 100.00 Hz 74.546 Hz
V. Total display
16.579 ms 9.997ms 13.410 ms
V. Active display
15.840 ms 9.387 ms 12.550 ms
V. Back porch
0.607 ms 0.548 ms 0.784 ms
V. Sync. Width
0.106 ms 0.047 ms 0.060 ms
H/V sync
polarity
+ / + + / + + / +
