17” CDT Color Monitor 107S7
74
2.6 Power Supply
2.6.1 Features
• AC line voltage range - 90Vac ~ 264Vac.
•
AC line frequency range - 50/60 Hz
±
3 Hz.
•
Input voltage transient - 300Vac for 10 seconds (China), 280Vac for 10 seconds (RoW).
•
Inrush current - < 50 A at 240Vac cold start.
•
Earth leakage current - < 1.0mA at 240Vac.
• Power factor correction - According to EN61000-3-2
Timing 7. 8. 9.
Resolution 1024 x 768 1024 x 768 1152 x 864
Pixel clock
65.000 MHz 75.000 MHz 108.000 MHz
H. Frequency 48.363 kHz 56.476 kHz 67.500 kHz
H. Total
20.677 us 17.707 us 14.815 us
H. Active display
15.754 us 13.653 us 10.667 us
H. Back porch
2.462 us 1.920 us 2.370 us
H. Sync. Width
2.092 us 1.813 us 1.185 us
V. Frequency 60.004 Hz 70.069 Hz 74.979 Hz
V. Total display
16.666 ms 14.272 ms 13.333 ms
V. Active display
15.880 ms 13.599 ms 12.678 ms
V. Back porch
0.600 ms 0.513 ms 0.568 ms
V. Sync. Width
0.124 ms 0.106 ms 0.044 ms
H/V sync
polarity
- / - - / - - / -
Timing 10.
Resolution 1280 x 960
Pixel clock
108.000 MHz
H. Frequency 60.000 kHz
H. Total
16.667 us
H. Active display
11.852 us
H. Back porch
2.889 us
H. Sync. Width
1.037 us
V. Frequency 60.000 Hz
V. Total display
16.667 ms
V. Active display
16.000 ms
V. Back porch
0.600 ms
V. Sync. Width
0.050 ms
H/V sync
polarity
+ / +
