17” CDT Color Monitor 107S7
75
2.6.2 Power consumption
It is equipped with two-stage power saving management. A delay of 5 seconds before entering the power saving
state is required to avoid misunderstanding of display resolution and timing mode changes.
• Power on - < 75w. (Test requirements refer to EN61000-3-2)
• Active off - < 2w at 120Vac / 240Vac.
•
Switch off - < 2w at 120Vac / 240Vac.
2.6.3 Power saving conditions
The monitor enters DPM off mode when no H&V sync or one of H-sync / V-sync input is absent. No message
appears before entering DPM mode.
2.6.4 Power recovery from power saving
Both H-sync and V-sync are detected.
2.7 User Controls / Indicators / Connectors
2.7.1 Front controls
• OSD menu is accessed by the keypad.
Key (R to L) Function
Power Tact DC switch
Menu OSD Menu
“ + ” Brightness/Adjust increase/Menu selection
“ - ” Contrast/Adjust decrease/Menu selection
High Brightness HB 4 levels hot key selection
• Access main menu by pressing “MENU” key.
• Select function via “+/-” & “MENU” keys, increase/decrease via “+/-” keys.
