USB Hub
USB Hub: About this product • Installation
About this product
Package Contents
Each package should include the following parts:
1 USB 4-port Clip-On HUB
●
1 USB cable●
1 Switching AC Adapter●
1 Owner's manual●
Features
Fulfill the USB-IF Specification Revision 1.1 and HID Class Definition Rev. 1.0●
Support up to 127 USB devices simultaneously.●
Stand-alone or clip-on to Philips monitor range.●
Support for realtime dynamic insertion and removal.●
1 Upstream port and 4 Downstream ports.●
Over current protection on all downstream ports.●
Self-powered by using the supplied AC Adapter or Bus-powered through USB bus.●
Identification
1) Power LED: Red light is lit when
power is supplied.
2) LEDs: Green light is lit for each of the
ports when they are connected and
active.
