3.3.2 Factory preset modes
Factory modes and preset modes are defined in the enclosed timing table file.
H.Freq. (KHz) Mode Resolution V.Freq. (Hz) BW(MHz)
31.469 IBM VGA 10H 640x350 70.086
31.469 IBM VGA 3H 720x400 70.087
31.469 IBM VGA 12H 640x480 59.94
35 MACINTOSH 640x480 67
37.861 VESA 640x480 72.809
37.5 VESA 640x480 75
43.269 VESA 640x480 85.008
35.156 VESA 800x600 56.25
37.879 VESA 800x600 60.317
48.077 VESA 800x600 72.188
46.875 VESA 800x600 75
53.674 VESA 800x600 85.061
49.7 MACINTOSH 832x624 75
56.4 - 960x720 75
44.75 - 960x720 60
48.363 VESA 1024x768 60.004
56.476 VESA 1024x768 70.069
60.023 VESA 1024x768 75.029
61.08 IBM XGA-2 1024x768 75.781
68.677 VESA 1024x768 84.997
CVT 2.3MA 1280 x768 60
60.289 CVT 2.3MA 1280 x768 75
54.1 1152x864 60
63.851 VESA 1152x864 70.012
67.5 VESA 1152x864 75
68.7 MACINTOSH 1152x870 75
61.845 SUN WS 1152x900 66.004
71.81 SUN WS 1152x900 76.15
60 VESA 1280x960 60
75 VESA 1280x960 75
63.981 VESA 1280x1024 60.02
71.691 SUN WS 1280x1024 67.189
76 DOS/V 1280x1024 72
79.976 VESA 1280x1024 75.025
81.13 SUN WS 1280x1024 76.11
91.1 VESA 1280x1024 85
44.772 - 1280x720 60
52.5 - 1280x720 70
64 CVT-reduced blanking 1400x1050 60 101
80 CVT 1400x1050 75 121.75
91.1 CVT 1400x1050 85 156
55.469 VESA-reduced blanking mode 1440x900 59.901 88.75
55.935 VESA 1440x900 59.887 106.5
70.635 VESA 1440x900 74.984 136.75
75 VESA 1600x1200 60 161
66.587 CVT 2.3MA-R 1920x1080 60.0 (for DVI-D 138.5
65.29 CVT1.76MW 1680x1050 60 146
CVT1.76MW-R 1680x1050 60 119
