Philips 190V7 - Page 25

19” LCD Color Monitor 190V7
25
GND_A
+12V
C470
0.001uF
+
C707
100uF/25V
+
C712
100uF/25V
DVDD
C706
0.1uF/16V
VOLUME
715G1767-1
+5V
BL-ON
EAR_SENSE
FB706
NC
Scaler Power
0.1A4
45Friday, January 06, 2006
Title
Size Document Number Rev
Date: Sheet
of
GND_A
+1V8
D701
FA20-04
+
C709
100uF/25V
C704
0.1uF/16V
FB707
120 OHM
CONNECTOR FOR
POWER/INVERTER
BOARD 2.0 mm
R495
NC
OUT-L+
+5V
C702
0.1uF/16V
C705
0.1uF/16V
D702
FA20-04
GND_A
+
C708
100uF/25V
CN702
8X2PIN/2mm
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
+
C710
100uF/25V
+5V
U701
MMC1085-33
1 2 3
ADJ(GND) VOUT(TAB) VIN
CN701
6x2PIN/2.0mm
2
4
6
8
10
12
1
3
5
7
9
11
STANDBY
PANEL_IDX
+12V
OUT-R-
R487
0 1/16W
FB703
120 OHM
VGA_3V3
CVDD1V8
R420
1K 1/16W
+
C711
100uF/25V
VGA_3V3
FB702
120 OHM
C469
0.001uF
FOR 3.3V POWER USE
R701
47 1/16W
BL-BRIGHT
FB701
120 OHM
OUT-R+
EAR-L
GND_A
MUTE
EAR-R
U702
MM1117-1.8
1 2 3
ADJ/GND OUTPUT INPUT
C701
0.001uF
C703
0.1uF/16V
OUT-L-
GND_A
FOR 1.8V POWER USE
