Philips 190V7 - Page 84

19” LCD Color Monitor 190V7
84
MODE NO. 5 6 7 8
RESOLUTION 640 x 480 640 x 480 640x480 800 x 600
Dot clock(MHz) 31.500 31.501 36 36
f h 37.861kHz 37.5kHz
36kHz
35.2kHz
A ( us ) 26.413(832 dots) 26.667 (840 dots) 23.111 (832 dots) 28.444(1024 dots)
B ( us ) 1.270(40 dots) 2.032 (54 dots) 1.556 (56 dots) 2.000 (72 dots)
C ( us ) 3.810(120 dots) 3.81 (120 dots) 2.222 (80 dots) 3.556 (128 dots)
D ( us ) 20.317(640 dots) 20.317 (640 dots) 17.778 (640 dots) 22.222(800 dots)
E ( us ) 1.016(32 dots) 0.508 (26 dots) 1.555 (56 dots) 0.666 (24 dots)
f v 72.809Hz 75Hz 85Hz 56Hz
O (ms ) 13.735(520 lines) 13.333 (500 lines) 11.763 (509 lines) 17.778 (625 lines)
P ( ms ) 0.079(3 lines) 0.08 (3 lines) 0.069 (3 lines) 0.057 (2 lines)
Q (ms ) 0.528(20 lines) 0.427 (16 lines) 0.578 (25 lines) 0.626 (22 lines)
R ( ms ) 12.678(480 lines) 12.8 (480 lines) 11.093 (480 lines) 17.066(600 lines)
S ( ms ) 0.45(17 lines) 0.026 (1 lines) 0.023 (1 lines) 0.029 (1 line)
SYNC. H/V -/- - / - -/- + / +
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 9 10 11 12
RESOLUTION 800 x 600 800 x 600 800 x 600 800 x 600
Dot clock(MHz) 40 50 49.498 56.251
f h 37.9kHz 48.077kHz 46.9kHz 53.7kHz
A ( us ) 26.4 (1056 dots) 20.80 (1040dots) 21.333(1056 dots) 18.631(1048 dots)
B ( us ) 3.2 (128 dots) 2.400 (120 dots) 1.616 (80 dots) 1.138 (64 dots)
C ( us ) 2.2 (88 dots) 1.280 (64 dots) 3.232 (160 dots) 2.702 (152 dots)
D ( us ) 20 (800 dots) 16.00 (800 dots) 16.162 (800 dots) 14.222 (800 dots)
E ( us ) 1 (40 dots) 1.120 (56 dots) 0.323 (16 dots) 0.569 (32 dots)
f v 60Hz 72Hz (72.188) 75Hz 85Hz
O (ms ) 16.579 (628 lines) 13.85 (666 lines) 13.333 (625 lines) 11.756(631 lines)
P ( ms ) 0.106 (4 lines) 0.125 (6 lines) 0.064 (3 lines) 0.056 (3 lines)
Q (ms ) 0.607 (23 lines) 0.478 (23 lines) 0.448 (21 lines) 0.503 (27 lines)
R ( ms ) 15.84 (600lines) 12.48 (600 lines) 12.8 (600 lines) 11.179 (600 lines)
S ( ms ) 0.026 (1 line) 0.770 (37 line) 0.021 (1 line) 0.018 (1 lines)
SYNC. H/V + / + + / + + / + + / +
POLARITY
SEP . SYNC Y Y Y Y
