Philips 190V7 - Page 86

19” LCD Color Monitor 190V7
86
MODE NO. 21 22 23 24
RESOLUTION 1152 x 864 1152 x 870 1152 x 900 1152 x 900
Dot clock(MHz) 108 100 94.5 108
f h 67.5kHz 68.7kHz 61.8kHz 71.8kHz
A ( us ) 14.815(1600 dots) 14.56 (1456 dots) 16.169(1528 dots) 13.926 (1054dots)
B ( us ) 1.185 (128 dots) 1.28 (128 dots) 1.354 (128 dots) 1.185 (128 dots)
C ( us ) 2.37 (256 dots) 1.44(144 dots) 2.201 (208 dots) 1.778 (192 dots)
D ( us ) 10.667 (1152 dots) 11.52 (1152 dots) 12.19 (1152 dots) 10.667 (1152 dots)
E ( us ) 0.593 (64 dots) 0.32 (32 dots) 0.424 (40 dots) 0.296 (32 dots)
f v 75Hz 75Hz 66Hz 76Hz
O (ms ) 13.333 (900 lines) 13.333 (916 lines) 15.151 (937lines) 13.132 (943 lines)
P ( ms ) 0.044 (3 lines) 0.044 (3 lines) 0.065 (4 lines) 0.111 (8 lines)
Q (ms ) 0.474 (32 lines) 0.568(39 lines) 0.501 (31 lines) 0.46 (33 lines)
R ( ms ) 12.8 (864 lines) 12.678 (870 lines) 14.552 (900lines) 12.533 (900 lines)
S ( ms ) 0.015 (1 lines) 0.043 (4 line) 0.033 (2 line) 0.028 (2 lines)
SYNC. H/V - / - - / - Serr- + / +
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 25 26 27 28
RESOLUTION 1280 x 960 1280 x 960 1280 x 1024 1280 x 1024
Dot clock(MHz) 108 129.895 108 117
f h 60kHz 75kHz 64kHz 71.7kHz
A ( us ) 16.667(1800 dots) 13.307(1728 dots) 15.63 (1688 dots) 13.949(1632 dots)
B ( us ) 1.037(112 dots) 1.047 (136 dots) 1.037 (112 dots) 0.957 (112 dots)
C ( us ) 2.889(312 dots) 1.725 (224 dots) 2.296 (248 dots) 1.915 (224 dots)
D ( us ) 11.852(1280 dots) 9.857 (1280 dots) 11.852 (1280 dots) 10.94 (1280 dots)
E ( us ) 0.889(96 dots) 0.678 (88 dots) 0.445 (48 dots) 0.137 (16 dots)
f v 60Hz 75Hz 60Hz 67Hz
O (ms ) 16.667(1000 lines) 13.333(1002 lines) 16.661(1066 lines) 14.883 (1067lines)
P ( ms ) 0.05(3 lines) 0.039 (3 lines) 0.047 (3 lines) 0.112 (8 lines)
Q (ms ) 0.600(36 lines) 0.48 (36 lines) 0.594 (38 lines) 0.46 (33 lines)
R ( ms ) 16(960 lines) 12.774 (960 lines) 16.005(1024 lines) 14.283(1024 lines)
S ( ms ) 0.017(1 lines) 0.04 (3 lines) 0.015 (1 line) 0.028 (2 lines)
SYNC. H/V +/+ + / + + / + + / +
POLARITY
SEP . SYNC Y Y Y Y
