19” LCD Color Monitor 190V7
90
5.6 Resins
• RoHS required
• WEEE required.
• Resin type/selection refer to Project Book Section 7.2 Plastic material.
5.7 If paint is used
• RoHS required
• WEEE require
5.8 Plastic mold tooling
• Tooling to be designed to minimize cosmetic defects induced by molding process (sink, blush, weld lines,
gate marks, ejector marks, etc.).
• Painting to cover up cosmetic defects due to molding is strongly discouraged.
5.9 Plastics flammability
• All Plastics to be Flame Retardant UL 94-V0 or Better (if monitor weighs less than 18kg; UL94-V0 is OK).
• All major plastic parts (bezel, back cover, base
) need to be molded from same resin.
5.10 Texture/Glossing of housing
• The texture area and texture no should follow Philips make-up sheet.
• The exterior surfaces shall have a uniform texture.
• Philips must approve the mold texturing.
• Detail document for texture refer to UAN-D249.
• < = 20 gloss units
5.11 Tilt and swivel base
Tilt angle: -5 ° to +25 °
5.12 Label
Regulatory label / Carton label should follow Philips requirement.
• Detail document refer to Philips Engineering Reference Book.
5.13 Product dimension / Weight
• Unit dimension (incl. pedestal) : 424(W) * 417.4 (H) * 235 (D) mm
• Packed unit dimension (carton) : 453 W* 486 H* 251 Dmm( for other regions )
• Net weight : 5.7Kg (Including I/F cable 240 g)
• Gross weight : 7.6Kg( for other regions )
5.14 Transportation
Transportation standards refer to TYE-M0002.
