3
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive
surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static type solder removal device. Some solder removal devices not classified as Yanti-
staticY can generate electrical charges sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES
devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are
ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam,
aluminum foil or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch
the protective material to the chassis or circuit assembly into which the device will be installed.
CAUTION: Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless
motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted Qoor
can generate static electricity sufficient to damage an ES device.)
2-7. Ordering Spare Parts
Please include the following informations when you order parts. (Particularly the Version letter)
1. Model number, Serial number and Software Version
The model number and Serial number can be found on the back of each product and the Software Version can
be found at the Spare Parts List.
2. Spare Part No. and Description
You can find them in the Spare Parts List
2-8. Photo used in this manual
The illustration and photos used in this Manual may not base on the final design of products, which may differ
from your products in some way.
3. How to Read this Instruction
Using Icons:
Icons are used to attract the attention of the reader to specific information. The meaning of each icon is described
in the table below:
Note:
A “note” provides information that is not indispensable, but may nevertheless be valuable to the reader, such as
tips and tricks.
Caution:
A “caution” is used when there is danger that the reader, through incorrect manipulation, may damage equipment,
loose data, get an unexpected result or has to restart(part of) a procedure.
