Cabinet Replacement Parts Lists
Model 27PT40B101
Ref. Ill
No.
S Part Number Description
SPEAKER 11 2422 264 00322 "Speaker, 8 Watts, 8 ohm (2 Used)"
CNV/PUR 8 S 2422 549 43385 Convergence and Purity Assembly
REM/TRAN 3104 207 09301 "Remote Transmitter, RC2010/01"
DEGAUSC 9 S 3121 218 62701 Degaussing Coil
AC/
CORD 12 S 3135 010 05051
AC Power Cord
OWN/MAN 3135 015 12911 Owner's Manual
IR/BLAST 3135 017 00921 IR Blaster
DEG/SPR 3139 121 26231 Degaussing Coil Spring
CABBACK 15 3139 124 29401 Cabinet Back
PWR/BTN 3 3139 124 29411 Power Button
CTR/BTN 4 3139 124 30051 Control Buttons
CHASFRM 14 3139 124 30211 Chassis Frame
CABFRNT 1 3139 137 60381 Cabinet Front
YOKE 7 S 3313 203 01242 "Yoke, AT6027/20"
ANO/CLP
6 4835 256 97264
Anode Clip
YOK/WDG 4835 535 27006 Yoke Wedge (3 Used)
BATTERY 9299 000 10137 Batteries for Remote Transmitter
CRT 5 S 9301 787 60472 "CRT, A68AJB82X"
Model 29LP692201, 3201
Ref. Ill
No.
S Part Number Description
SPEAKER 11 2422 264 00322 "Speaker, 8 Watts, 8 ohm (2 Used)"
CNV/PUR 8 S 2422 549 43385 Convergence and Purity Assembly
DEGAUSC 9 S 3121 218 62701 Degaussing Coil
ADAPTOR
3135 010 03071
AC Adaptor (3201)
AC/CORD
12 S 3135 010 06381 "AC Power Cord, Non-Polarized"
OWN/MAN 3135 015 12931 "Owner's Manual, Spanish (2201)"
OWN/MAN 3135 015 12951 "Owner's Manual, Spanish (3201)"
DEG/SPR 3139 121 26231 Degaussing Coil Spring
CABBACK 15 3139 124 25280 Cabinet Back
LT/GUIDE 13 3139 124 25351 Light Guide
CTR/BTN 4 3139 124 26741 Control Buttons
PWR/BTN 3 3139 124 26753 Power Button
CHASFRM 14 3139 124 30211 Chassis Frame
REM/TRAN 3139 128 75601 "Remote Transmitter, RCU81AX"
CABFRNT 1 3139 137 66881 Cabinet Front
YOKE 7 S 3313 203 01242 "Yoke, AT6027/20"
ANO/CLP
6 4835 256 97264
Anode Clip
NAMEPLT 2 4835 459 17546 "Nameplate, Large"
YOK/WDG 4835 535 27006 Yoke Wedge (3 Used)
BATTERY 9299 000 10137 Batteries for Remote Transmitter
CRT 5 S 9301 787 60472 "CRT, A68AJB82X"
