G7 CHASSIS FEATURE WORDS
Chart No. Final Chassis Trans- Antenna Audio Auto Auto Auto Standby Muliple A/V Compress Customer Dynamic Noise Expand Mono Fine Hospitality Incredible PIP Parental
Instrument
Assembly
mitter
A/B
Control
Standby
Volume L
No Picture
Inputs
16 x 9
Service Mode
Reduction
14 x 9
Str A/V
Tuning
Mode
Control
Lock
AB AD AK AL AN AV CM CS DN EX FM FT HO IP PI PL Feature Byte Values
EEPROM ADR 3 b7 3 b6 3 b5 3 b4 3 b3 3 b2 3 b1 3 b0 4 b7 4 b6 4 b5 4 b4 4 b3 4 b2 4 b1 4 b0 Byte # 3 4 5 6 7 8 9
27A950/37R TP2784C1 EMG770 RCU81B 0 1 0 1 0 1 0 1 1 0 0 1 0 0 1 1 85 147 47 188 0 0 0
27A950/35R XP2784C1 EMG770 RCU81B 0 1 0 1 0 1 0 1 1 0 0 1 0 0 1 1 85 147 47 188 0 0 0
27A985/37R TP2797B1 EMG772 RCU81E 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 239 188 0 0 0
27A975/85R 29LP6922 EMG771 RCU81AX 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 141 160 0 0 0
27A976/87R 29LP6932 EMG773 RCU81AX 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 141 160 0 0 0
32A940/37R TS3259C1 EMG780 or EMG785 RCU81BX 0 1 0 1 0 1 0 1 1 0 0 1 0 0 0 1 85 145 46 188 0 0 0
32A940/35R XS3259C1 EMG780 or EMG785 RCU81BX 0 1 0 1 0 1 0 1 1 0 0 1 0 0 0 1 85 145 46 188 0 0 0
32A950/37R TP3284C1 EMG782 or EMG787 RCU81B 0 1 0 1 0 1 0 1 1 0 0 1 0 0 1 1 85 147 47 188 0 0 0
32A985/37R TP3297B1 EMG784 or EMG788 RCU81E 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 239 188 0 0 0
32A960/85R 33LL8911 EMG783 or EMG710 RCU81BX 0 1 0 1 0 1 0 1 1 0 0 1 0 0 0 1 85 145 12 160 0 0 0
32A976/87R 33LP8932 EMG781 or EMG789 RCU81AX 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 141 160 0 0 0
36A940/37R TS3659C1 EMG790 or EMG796 RCU81BX 0 1 0 1 0 1 0 1 1 0 0 1 0 0 0 1 85 145 47 188 0 0 0
36A940/35R XS3659C1 EMG790 or EMG796 RCU81BX 0 1 0 1 0 1 0 1 1 0 0 1 0 0 0 1 85 145 47 188 0 0 0
36A950/37R TP3684C1 EMG792 or EMG798 RCU81B 0 1 0 1 0 1 0 1 1 0 0 1 0 0 1 1 85 147 47 188 0 0 0
36A985/37R TP3697B1 EMG794 or EMG799 RCU81E 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 239 188 0 0 0
36A975/85R 37LP9922 EMG791 or EMG797 RCU81AX 1 1 0 1 0 1 0 1 1 0 0 1 0 1 1 1 213 151 141 160 0 0 0
Chart No. Final Chassis Trans- PIP Remote Smart Number Speaker Auto Stby First Time Comb Incred. Pix Sync Timer V-Chip V-Chip V-Chip
Instrument Assembly mitter Tuner Locator Clock of A/Vs On/Off Auto On Setup Filter Via Menu Slice L. On/Off Un-Rated No Rating
PT RL SC SO SP ST SU CF IM VS TM VC VU VN
EEPROM ADR 5 b7 5 b6 5 b5 5 b4 5 b3 5 b2 5 b1 5 b0 6 b7 6 b6 6 b5 6 b4 6 b3 6 b2
27A950/37R TP2784C1 EMG770 RCU81B 0 0 1 0 1 1 1 1 1 0 1 1 1 1
27A950/35R XP2784C1 EMG770 RCU81B 0 0 1 0 1 1 1 1 1 0 1 1 1 1
27A985/37R TP2797B1 EMG772 RCU81E 1 1 1 0 1 1 1 1 1 0 1 1 1 1
27A975/85R 29LP6922 EMG771 RCU81AX 1 0 0 0 1 1 0 1 1 0 1 0 0 0
27A976/87R 29LP6932 EMG773 RCU81AX 1 0 0 0 1 1 0 1 1 0 1 0 0 0
32A940/37R TS3259C1 EMG780 or EMG785 RCU81BX 0 0 1 0 1 1 1 0 1 0 1 1 1 1
32A940/35R XS3259C1 EMG780 or EMG785 RCU81BX 0 0 1 0 1 1 1 0 1 0 1 1 1 1
32A950/37R TP3284C1 EMG782 or EMG787 RCU81B 0 0 1 0 1 1 1 1 1 0 1 1 1 1
32A985/37R TP3297B1 EMG784 or EMG788 RCU81E 1 1 1 0 1 1 1 1 1 0 1 1 1 1
32A960/85R 33LL8911 EMG783 or EMG710 RCU81BX 0 0 0 0 1 1 0 0 1 0 1 0 0 0
32A976/87R 33LP8932 EMG781 or EMG789 RCU81AX 1 0 0 0 1 1 0 1 1 0 1 0 0 0
36A940/37R TS3659C1 EMG790 or EMG796 RCU81BX 0 0 1 0 1 1 1 1 1 0 1 1 1 1
36A940/35R XS3659C1 EMG790 or EMG796 RCU81BX 0 0 1 0 1 1 1 1 1 0 1 1 1 1
36A950/37R TP3684C1 EMG792 or EMG798 RCU81B 0 0 1 0 1 1 1 1 1 0 1 1 1 1
36A985/37R TP3697B1 EMG794 or EMG799 RCU81E 1 1 1 0 1 1 1 1 1 0 1 1 1 1
36A975/85R 37LP9922 EMG791 or EMG797 RCU81AX 1 0 0 0 1 1 0 1 1 0 1 0 0 0
Chart No. Final Chassis Trans- Antenna Audio Auto Auto Auto Standby Muliple A/V Compress Customer Dynamic Noise Expand Mono Fine Hospitality Incredible PIP Parental
Instrument Assembly mitter A/B Control Standby Volume L No Picture Inputs 16 x 9 Service Mode Reduction 14 x 9 Str A/V Tuning Mode Picture Control Lock
AB AD AK AL AN AV CM CS DN EX FM FT HO IP PI PL Feature Byte Values
EEPROM ADR 3 b7 3 b6 3 b5 3 b4 3 b3 3 b2 3 b1 3 b0 4 b7 4 b6 4 b5 4 b4 4 b3 4 b2 4 b1 4 b0 Byte # 3 4 5 6 7 8 9
27FSQ985/37R 27PT40B1 EMG774 RC2010 1 1 0 1 0 1 0 1 1 0 0 0 0 1 1 1 213 135 175 222 224 0 0
32FSQ985/37R 32PT70B1 EMG786 RC2010 1 1 0 1 0 1 0 1 1 0 0 0 0 1 1 1 213 135 191 222 224 0 0
Chart No. Final Chassis Trans- PIP Remote Smart Number Speaker Auto Stby First Time Comb Incred. Pix Virtual Sync Timer D Window D Window Guide Go to
Instrument Assembly mitter Tuner Locator Clock of A/Vs On/Off Auto On Setup Filter Via Menu Dolby Slice L. 4:3 16:9 Plus Guide+
PT RL SC SO SP ST SU CF IM VD VS TM W1 W2 GP GG
EEPROM ADR 5 b7 5 b6 5 b5 5 b4 5 b3 5 b2 5 b1 5 b0 6 b7 6 b6 6 b5 6 b4 6 b3 6 b2 6 b1 6 b0
27FSQ985/37R 27PT40B1 EMG774 RC2010 1 0 1 0 1 1 1 1 1 1 0 1 1 1 1 0
32FSQ985/37R 32PT70B1 EMG786 RC2010 1 0 1 1 1 1 1 1 1 1 0 1 1 1 1 0
Chart No. Final Chassis Trans- V-Chip V-Chip V-Chip Expand
Instrument Assembly mitter On/Off
Un-Rated
No Rating
4:3
VC VU VN EP
EEPROM ADR 7 b7 7 b6 7 b5 7 b4
27FSQ985/37R 27PT40B1 EMG774 RC2010 1 1 1 0
32FSQ985/37R 32PT70B1 EMG786 RC2010 1 1 1 0
