30
a TV ANTENNA
Signal input from an antenna, cable or
satellite.
b EXT 1 and EXT 2 (CVBS and RGB)
Analogue audio and video input from
analogue or digital devices such as DVD
players or game consoles.
c SPDIF OUT
Digital audio output to home theatres
and other digital audio systems.
TV ANTENNA
SPDIF OUT
7 Connect devices
This section describes how to connect devices
with different connectors. Examples are
provided in the Quick Start.
Note
You can use different types of connectors to •
connect a device to your TV.
Back connector
