18
TPT1.1A LA
5. Service Modes, Error Codes and Fault Finding
5. Service Modes, Error Codes and Fault Finding
index of this chapter:
5.1 CSM
5.2 Factory Mode
5.
3 Repair Flow Chart
5.1 CSM
It can display CSM windows message when press 1-2 3-6 5-4 on the button (RC) remote control in normal operation mode.
The following information is displayed on screen:
About error code,Please refer to the table below.
Error code Event
0x01 Audio decoder Error
0x02 IIC bus error
0x03 Tuner error
0x04 NVRAM Error
0x05 Scaler Chip error
CSM Item Contents Remark
1: Set Type 42TA2800/98 Project name
2: Production code BZ000651123456 14 digit production-code(serial number)
3: SW-naming main-processor
TA2800 42LPL V1.13G 20070328 AP
SECAM98 Factory Power OFF
SW version(TA2800:project name, V1.13G: software version,
20070328: software release date, SECAM98 Factory Power
OFF: region )
4: Code 1 FF FF FF FF FF Error codes in NVM/EEPROM (5 last logged errors)
5: Code 2 FF FF FF FF FF Error codes in NVM/EEPROM (5 first logged errors)
6: Key (HDCP) Invalid HDMI information whether HDCP-key is valid
7: Digital signal quality ATSC Digital signal level
8: NVM-naming PANEL_LPL_42_WX5 Contents per Panel-type
