Philips 32PFS5603/12 - Page 49

9-3-12 HOTEL function
IR_RC
C4228
NC/1N 50V
C4230
NC/1N 50V
R4344 NC/0R
C4232
NC/1N 50V
C4231
NC/1N 50V
IRIN
C4229
NC/1N 50V
CN606
NC/CONN
1
2
3
4
5
6
7
8
9
10
11
12
1314
R4345 NC/0R
IR_RC 4
AUOUT_R0
4
AUOUT_L0
4
BATH_AMP_EN
4
Bathroom SPK audio out for BUH
AUOUT_R0
AUOUT_L0
BATH_L_R
UART-RX
UART-TX
BATH_AMP_EN
STANDBY
IR_RC
BATH_AMP_EN
AUOUT_L0
AUOUT_R0
For BUH daughter board
STANDBY
3
STANDBY
IRIN 4
IRIN
+3.3V_Standby
+5V_Normal
UART-RX
4,6,8
UART-TX
4,6,8
UART-TX
UART-RX
BATH_L_R
