Philips 32PW9618 - Page 162

Spare Parts List
EN 162 EM6E10.
6110 9340 418 70133 BYV27-600
6111 4822 130 11596 BYW29EX-200
6113 4822 130 11596 BYW29EX-200
6114 4822 130 41601 BYV95A
6114 4822 130 42488 BYD33D
6115 4822 130 11528 1PS76SB10
6116 3198 020 55680 BZX384-C5V6
6117 9340 548 71115 SM PDZ33B
6118 9340 548 71115 SM PDZ33B
6119 9340 548 71115 SM PDZ33B
6120 4822 130 30621 1N4148
6121 4822 130 30621 1N4148
6122 3198 010 53980 BZX79-B3V9
6130 9340 548 61115 PDZ12B
6131 4822 130 11397 BAS316
6132 4822 130 11416 PDZ6.8B
6133 4822 130 11397 BAS316
6134 4822 130 11397 BAS316
6141 4822 130 11522 UDZ15B
6142 4822 130 11528 1PS76SB10
6143 4822 130 11397 BAS316
6144 4822 130 11397 BAS316
6147 4822 130 33657 BZV85-C6V8
6148 4822 130 11397 BAS316
6149 3198 020 55680 BZX384-C5V6
6400 4822 130 70055 BYV27-400
6402 4822 130 11397 BAS316
6403 9340 548 52115 PDZ5.1B
6404 4822 130 11397 BAS316
6405 4822 130 34383 BZX79-B47
6406 4822 130 11397 BAS316
6407 4822 130 11397 BAS316
6408 4822 130 42488 BYD33D
6408 5322 130 31938 BYV27-200
6421 4822 130 10753 BY359X-1500
6422 4822 130 10218 BY229X-800
6442 4822 130 11522 UDZ15B
6455 4822 130 11397 BAS316
6456 5322 130 34337 BAV99
6457 9322 102 64685 UDZ2.7B
6458 3198 020 55680 BZX384-C5V6
6460 4822 130 41487 BYV95C
6462 9322 127 32682 BYW76-RAS15/10
6464 9322 127 32682 BYW76-RAS15/10
6480 4822 130 42488 BYD33D
6480 5322 130 31938 BYV27-200
6481 4822 130 11522 UDZ15B
6482 4822 130 11397 BAS316
6483 4822 130 11528 1PS76SB10
6493 4822 130 11528 1PS76SB10
6499 4822 130 11551 UDZS10B
6505 4822 130 34281 BZX79-B15
6506 4822 130 80622 BAT54
6507 4822 130 11397 BAS316
6509 4822 130 11397 BAS316
6510 4822 130 34142 BZX79-B33
6511 4822 130 11397 BAS316
6512 4822 130 11397 BAS316
6514 5322 130 31932 BZT03-C200
6515 4822 130 33657 BZV85-C6V8
6516 4822 130 11397 BAS316
6517 4822 130 11528 1PS76SB10
6518 9340 548 69115 PDZ27B
6519 4822 130 42488 BYD33D
6519 5322 130 31938 BYV27-200
6520 4822 130 30621 1N4148
6522 4822 130 11397 BAS316
6523 4822 130 80622 BAT54
6525
 4822 130 10741 GBU6J
6530 4822 130 41487 BYV95C
6533 4822 130 80622 BAT54
6534 9322 165 72687 DTV1500MFP
6534
 9340 558 96127 BYV29X-600
6535 4822 130 11572 STPS8H100F
6536 4822 130 11572 STPS8H100F
6537 4822 130 11397 BAS316
6614 4822 130 11528 1PS76SB10
6615 4822 130 11397 BAS316
6616 4822 130 11397 BAS316
6617 4822 130 11397 BAS316
6618 4822 130 11397 BAS316
6619 4822 130 42488 BYD33D
6619 5322 130 31938 BYV27-200
6620 5322 130 31938 BYV27-200
6621 4822 130 42488 BYD33D
6621 5322 130 31938 BYV27-200
6622 5322 130 32296 BZV85-C10
6622 5322 130 33635 BZV85-C8V2
6623 4822 130 11397 BAS316
6624 4822 130 11397 BAS316
6625 4822 130 11397 BAS316
6626 4822 130 11397 BAS316
6627 4822 130 11397 BAS316
6701 4822 130 11397 BAS316
6745 4822 130 11551 UDZS10B

7100 4822 130 44568 BC557B
7101 4822 130 40981 BC337-25
7102 4822 130 11417 STP3NB60FP
7102
 9322 194 26687 STP6NK60Z
7103
 9322 149 04682 TCET1102
7105 4822 130 44568 BC557B
7120 5322 130 60159 BC846B
7130 5322 130 60159 BC846B
7131 4822 130 11336 STP16NE06FP
7140 5322 130 60159 BC846B
7141 4822 130 11336 STP16NE06FP
7210 5322 130 60159 BC846B
7211 4822 130 42804 BC817-25
7408 5322 130 44647 BC368
7409 5322 130 60159 BC846B
7421 9340 210 30127 BU2520DX
7440 4822 209 70672 LM358N SEL.
7441 4822 130 60373 BC856B
7442 4822 130 60373 BC856B
7443 5322 130 60159 BC846B
7445 5322 130 60159 BC846B
7450 5322 209 61472 LM393M
7455 4822 209 73852 PMBT2369
7480 4822 130 11417 STP3NB60FP
7482
 4822 130 11418 TCDT1102G
7486 5322 130 60159 BC846B
7487 5322 130 60159 BC846B
7501 5322 130 60159 BC846B
7502 4822 130 40981 BC337-25
7504 9322 171 30687 STP11NM60
7505 4822 130 60373 BC856B
7506 4822 209 14933 TL431IZ
7507 9322 149 04682 TCET1102
7508 4822 130 41646 BF423
7528 4822 130 40981 BC337-25
7529 4822 130 44461 BC546B
7530 5322 130 60159 BC846B
7611 5322 130 60159 BC846B
7612 5322 130 60159 BC846B
7613 4822 209 81397 TL431CLPST
7614 5322 130 60159 BC846B
7620 4822 209 90009 TDA8177
7641 5322 130 60159 BC846B
7652 5322 130 60159 BC846B
7653 5322 130 60159 BC846B
7654 4822 130 60373 BC856B
7680 4822 209 60956 TDA7052/N2
7681 5322 130 60159 BC846B
7682 5322 130 44647 BC368
7700 9322 163 86682 TDA7490L
7701 5322 130 60159 BC846B
7702 9322 163 86682 TDA7490L
7703 5322 130 60159 BC846B
7704 5322 130 60159 BC846B
7705 5322 130 60159 BC846B
7706 4822 130 60373 BC856B
7707 5322 130 60159 BC846B
Small Signal Panel [B]
Various
0031 3104 304 24941 SSB-Top frame
0072 3104 301 24191 Frame SSB A-side
0073 3104 301 24211 Cover SSB A-side
0074 3104 301 24221 Cover SSB Z-side
0075 3104 301 24201 Frame SSB Z-side
1001 2422 543 89022 Crystal 6MHz 20pF CX5F
1301 2422 540 98456 Resonator 12MHz
1305 2422 543 01184 Xtal 4.433619MHz 20pF
1308 2422 543 01183 Xtal 3.579545MHz 16pF
1402 2422 025 17103 Connector 3p m
1403
 2422 086 11031 Fuse SMD 500mA 63V
1407 2422 549 44324 Filt. TPWCC04BS
1408 2422 549 44372 SAW 38.9MHz K3953L
1409 2422 549 44369 SAW 38.9MHz K9656L
1702 2422 540 98456 Resonator 12MHz
1A00 2422 543 89019 Crystal 18.432MHz 12pF
1I01 4822 267 10771 Socket 2 x SCART
1I03 2422 025 16194 Socket 8P for transmitter
1I04 4822 267 10771 Socket 2 x SCART
1I05 4822 267 11033 Socket CINCH 3P f
1I06 2422 026 05289 Socket CINCH 6P f
1I70 2422 025 16966 Connector 5P m SMD
1P00 2422 543 01184 Xtal 4.433619MHz 20pF
1P03 2422 543 01183 Xtal 3.579545MHz 16pF
1P04 2422 549 44369 SAW 38.9MHz K9656L
1P06 2422 549 44372 SAW 38.9MHz K3953L
1P09 2422 549 44324 Filt. TPWCC04BS
1S02 2422 025 17682 Connector 40p M
1S15 2422 025 17682 Connector 40p M
1T01
 3139 147 19301 Tuner V+U PLL BGHIL
1T02 3139 147 19341 Tuner UV1318S/A I-3
1U01 2422 086 10964 Fuse T0.630A 63V 2410
8205 3104 311 05121 Cable 40P/180/40P
8206 3104 311 05301 Cable 40P/220/40P

2000 4822 124 12095 100µF 20% 16V
2001 4822 124 12095 100µF 20% 16V
2002 4822 126 11669 27pF 5% 50V 0603
2003 4822 126 13879 220nF 20% 16V
2004 4822 126 13879 220nF 20% 16V
2005 2238 586 59812 100nF 20-80% 50V 0603
2006 2238 586 59812 100nF 20-80% 50V 0603
2007 2238 586 59812 100nF 20-80% 50V 0603
2008 2238 586 59812 100nF 20-80% 50V 0603
2010 4822 126 11785 47pF 5% 50V 0603
2011 4822 126 11785 47pF 5% 50V 0603
2012 4822 126 11785 47pF 5% 50V 0603
2013 2020 021 91557 100µF 20% 16V
2016 4822 124 12095 100µF 20% 16V
2017 2238 586 59812 100nF 20-80% 50V 0603
2018 2222 867 15339 33pF 5% 50V 0603
2019 2238 586 59812 100nF 20-80% 50V 0603
2020 4822 126 13883 220pF 5% 50V
2022 2238 586 59812 100nF 20-80% 50V 0603
2023 2238 586 59812 100nF 20-80% 50V 0603
2024 2238 586 59812 100nF 20-80% 50V 0603
2025 2238 586 59812 100nF 20-80% 50V 0603
2026 2238 586 59812 100nF 20-80% 50V 0603
2027 2238 586 59812 100nF 20-80% 50V 0603
2028 2238 586 59812 100nF 20-80% 50V 0603
2029 2238 586 59812 100nF 20-80% 50V 0603
2031 2238 586 59812 100nF 20-80% 50V 0603
2033 4822 126 14226 82pF 5% 50V 0603
2034 4822 126 14226 82pF 5% 50V 0603
2035 4822 126 14226 82pF 5% 50V 0603
2036 4822 126 14226 82pF 5% 50V 0603
2037 4822 126 14226 82pF 5% 50V 0603
2038 2238 586 59812 100nF 20-80% 50V 0603
2039 2238 586 59812 100nF 20-80% 50V 0603
2040 2238 586 59812 100nF 20-80% 50V 0603
2062 2238 916 15641 22nF 10% 25V 0603
2063 3198 017 34730 47nF 16V 0603
2064 2238 916 15641 22nF 10% 25V 0603
2066 3198 017 34730 47nF 16V 0603
2067 2238 586 59812 100nF 20-80% 50V 0603
2068 4822 126 14238 2.2nF 50V 0603
2069 4822 121 70159 0.1µF 16V
2302 2238 586 59812 100nF 20-80% 50V 0603
2303 4822 122 33177 10nF 20% 50V
2304 4822 122 33741 10pF 10% 50V
2305 2238 586 59812 100nF 20-80% 50V 0603
2306 4822 126 13881 470pF 5% 50V
2307 2238 586 59812 100nF 20-80% 50V 0603
2308 4822 122 33741 10pF 10% 50V
2312 2020 552 96659 33nF 5% 50V 1206
2313 2020 552 96685 100nF 5% 25V 1206
2314 2020 021 91557 100µF 20% 16V
2315 2238 586 59812 100nF 20-80% 50V 0603
2316 2238 586 59812 100nF 20-80% 50V 0603
2317 2020 552 96448 1µF 10% 16V
2318 2238 916 15641 22nF 10% 25V 0603
2319 5322 126 11578 1nF 10% 50V 0603
2320 4822 122 33741 10pF 10% 50V
2321 2238 586 59812 100nF 20-80% 50V 0603
2322 2238 586 59812 100nF 20-80% 50V 0603
2323 2238 586 59812 100nF 20-80% 50V 0603
2324 5322 126 11583 10nF 10% 50V 0603
2325 2238 586 59812 100nF 20-80% 50V 0603
2326 5322 126 11583 10nF 10% 50V 0603
2328 4822 122 33761 22pF 5% 50V
2329 2238 586 59812 100nF 20-80% 50V 0603
2330 2238 586 59812 100nF 20-80% 50V 0603
2331 2238 586 59812 100nF 20-80% 50V 0603
2332 2238 586 59812 100nF 20-80% 50V 0603
2333 4822 126 14491 2.2µF -20+80% 10V 0805
2334 4822 126 14491 2.2µF -20+80% 10V 0805
2335 5322 126 11578 1nF 10% 50V 0603
2336 4822 126 14491 2.2µF -20+80% 10V 0805
2337 4822 126 14487 8.2pF 0.5% 50V 0603
2338 4822 126 14487 8.2pF 0.5% 50V 0603
2340 2020 021 91557 100µF 20% 16V
2341 4822 126 14487 8.2pF 0.5% 50V 0603
2343 2238 586 59812 100nF 20-80% 50V 0603
2350 2238 586 59812 100nF 20-80% 50V 0603
2351 2238 586 59812 100nF 20-80% 50V 0603
2352 2238 586 59812 100nF 20-80% 50V 0603
