11
2. Setting up the monitor
MultiView in OSD menu
• PIP / PBP Mode: There are two
modes for MultiView: [PIP] and
[PBP].
[PIP]: Picture in Picture
Open up a sub-window
of another signal source.
B
A (main)
When the sub source is
not detected:
B
A (main)
[PBP]: Picture by Picture
Open up a sub-window
side-by-side of another
signal source.
A (main) B
When the sub source is
not detected:
A
Note
The black strip shows on the top and
the bottom of the screen for the correct
aspect ratio when in the PBP mode.
• PIP / PBP Input: There are three
different video input to choose as
the sub display source: [HDMI 1.4],
[HDMI 2.0], and [DisplayPort].
• PIP Size: When PIP is activated,
there are three sub-window sizes to
choose: [Small], [Middle], [Large].
B
A (main)
Small
Middle
Large
• PIP Position: When PIP is activated,
there are four sub-window positions
to choose.
Top-Right Bottom-Right
B
A (main)
A (main)
B
Top-Left Bottom-Left
B
A (main)
A (main)
B
• Swap: The main picture source
and the sub picture source
swapped on the display.
Swap A and B source in [PIP] mode:
B
A (main)
↔
B (main)
A
Swap A and B source in [PBP] mode:
A (main) B
↔
B (main) A
• Off: Stop MultiView function.
A (main)
Note
When you do the SWAP function,
the video and its audio source will
swap at the same time. (Refer to page
7 “Independent audio playback,
regardless of video input” for more
detail.)
