2.4 Remove the Base Assembly
for VESA Mounting
Before you start disassembling the
Display base, please follow the
instructions below to avoid any possible
damage or injury.
1. Place the monitor face down on soft
and smooth surface taking care to
avoid scratching or damaging the
screen.
2. While keeping the release button
pressed, tilt the base and slide it
out.
Note
This monitor accepts a 100mm x 100mm
VESA-Compliant mounting interface.
100mm
100mm
