5. Service Modes, Error Codes and Fault Finding
5. Service Modes, Error Codes and Fault Finding
index of this chapter:
5.1 CSM
5.2 Factory Mode
5.
3 Repair Flow Chart
5.1 CSM
It can display CSM windows message when press 1-2 3-6 5-4 on the button (RC) remote control in normal operation mode.
The following information is displayed on screen:
About error code,Please refer to the table below.
Error code Event
0x01 Audio decoder Error
0x02 IIC bus error
0x03 Tuner error
0x04 NVRAM Error
0x05 Scaler Chip error
CSM Item Contents Remark
1: Set Type 47PFL7422/93 model name
2: Production code BZ000651123456 14 digit production-code(serial number)
3: SW-naming main-processor 37 47LPL_1080_ V0010.0 20070302 CHINA 93
SW version(37 47:size, LPL_1080_: panel&input, V0010.0:
software version, 20070302: software release date)
4: SW-naming other-processor STF31E 1.0
5: Code 1 FF FF FF FF FF Error codes in NVM/EEPROM (5 last logged errors)
6: Code 2 FF FF FF FF FF Error codes in NVM/EEPROM (5 first logged errors)
7: Key (HDCP) -HDMI Enabled HDMI information whether HDCP-key is valid
8: Analogue signal strength 255
