Attaching the Base
You must attach the base to the Unit to have it as a table top Unit.
Be sure the front and rear of the base match the proper direction. For large screen TVs, at least 2 people are required for these steps.
65PFL4909
1
2
× 4
55PFL4909 / 55PFL4609 / 50PFL4909 / 49PFL4909 / 49PFL4609
1
2
× 4
43PFL4909 / 40PFL4909
1
× 3
M4 x 0.787” (20mm)
2
2
1
3
× 2
M4 x 0.393” (10mm)
4
10
.English
Continued on next page.
