Service Modes
Service Default Alignment Mode (SDAM) offers several features for the service
technician, while the Customer Service Mode (CSM) is used for communication
between the servicer and the customer.
The T8 chassis also offers the option of using ComPair, a hardware interface between a
computer and the TV chassis. It offers the abilities of structured troubleshooting, error
code reading, and software version readout for all T8 chassis. Minimum requirements
for ComPair: a 486 processor, Windows 3.1 and a CD-ROM drive.
Note: ComPair products will become available as they are developed.
Table: Service Modes
SW Cluster
Software
name
UOC type
UOC
Diversity
Special
Features
2US9 L01UM9x.y TDA9577(SS)
55K
ROM
Size
Mono
(Magnavox)
3US2 L01UN2x.y
TDA9577
(SS) (LS)
55K
ROM
Size
Stereo non-
dBx
(Magnavox)
1US5 L01US5x.y
TDA9588
(LS)
64K
ROM
Size
Stereo non-
dBx
(Magnavox),
Non PIP
2US2 L01UM2x.y
TDA9577
(LS)
55K
ROM
Size
Mono
(Philips)
