Error Codes
In case of non-intermittent faults, write down the errors present in the error buffer and
clear the error buffer before you begin the repair.
This ensures that old error codes are no longer present.
If possible, check the entire contents of the error buffer. In some situations an error
code is only the result of another error and not the actual cause of the problem (for
example, a fault in the protection detection circuitry can also lead to a protection).
Table: Error Code Table
ERROR
Device
Error
description
Check
item
Diagram
0 Not applicable No Error
1 Not applicable
X-Ray
Protection
2465,
7460
A2
2 Not applicable
Horizontal
Protection
7460,
7461,
7462,
7463,
6467
A2
3 TDA8359/TDA9302
Vertical
Protection
7861,
VloAux
+13v
A2, A3
4 MSP34X5/TDA9853
MAP I2C
identification
error
7831,
7861
A9 or
A11
5 TDA95XX
POR 3.3V /
8V Protection
7200,
7560,
7480
A1, A2.
A5, A6,
A7
