Philips AZ 2555 - Mechanical Partslist

12 - 212 - 2
401 3140 117 66681 BUTTON TREE PNT PRT
402 3140 117 66671 PLAY/PAUSE BUTTON PNT PRT
403 3140 114 49271 LIGHT GUIDE-LCD
404 3140 114 49231 BRACKET-LCD
406 3140 114 49261 LIGHT GUIDE-VU
407 3140 117 66661 WOOX BUTTON PRT
408 3140 117 66541 FRONT PANEL ASSY
409 3140 117 66561 FRONT CABINET ASSY
411 4822 529 10387 DAMPER - RUBBER (40 DEG)
412 4822 529 10386 DAMPER - RUBBER (30 DEG)
413 3140 117 66611 POWER-SOURCE BUTTON PNT PRT
414 3140 117 66711 VOLUME KNOB ASSY
416 3140 117 59800 CLAMPER RING ASSY CDM-DA11
417 3140 117 66601 CD DOOR PRT
418 3140 117 66621 CD DOOR DETAIL PRT
419 4822 529 10322 DAMPER ASSY
421 3140 111 22761 SPRING-CD (LONG)
422 4822 263 21206 P50 ADAPTOR
423 3140 118 01541 CD TRAY ASSY AZ2555
424 4822 256 90463 HOLDER FERRITE BAR
426 3140 117 66531 BACK CABINET ASSY
427 3140 117 67111 HANDLE PNT
428 3140 117 66741 BASS PORT CAP PNT
429 3140 118 71790 ROD ANTENNA EXTEND 660MM
431 4822 492 51733 SPRING
432 3140 111 21320 CONTACT PLATE
433 3140 111 22951 SPRING-COMPRESSION
434 3140 117 68141 BATTERY DOOR PNT AZ2555
2422 070 98246 MAINSCORD UL 7A 1M5 DET 2P B
3139 228 61871 PROD.ASSY RC19621001/01 PACKED
3140 110 22391 CBLE USB-A/1500/USB-B
Note: Only these parts mentioned in the list are
normal service parts.
MECHANICAL PARTSLIST - CABINET
ELECTRICAL PARTSLIST - KEY BOARD
- MISCELLANEOUS - - CAPACITORS -
1101 4822 267 31996 CONNECTOR 1P 2418 2020 552 94427 100pF 5% NP0 50V
1150 2422 026 05099 CONNECTOR PHONE H 1P 2419 2020 552 94427 100pF 5% NP0 50V
1400 4822 267 10958 SOCKET FFC 5P 2420 2020 552 94427 100pF 5% NP0 50V
1401 4822 265 11535 SOCKET FFC 8P 2421 5322 126 11583 10nF 10% X7R 50V
1402 4822 265 11207 SOCKET FFC 6P 2422 4822 124 22651 1,0
µ
F 20% 50V
1405 4822 265 11184 SOCKET FFC 18P 2423 2238 586 59812 100nF +80-20% Y5V 50V
1406 4822 265 11207 SOCKET FFC 6P 2425 4822 126 14225 56
p
F 5% NP0 50V
1430 2422 128 02922 SWITCH-TACT 2426 4822 122 33752 15pF 5% NP0 50V
1431 2422 128 02922 SWITCH-TACT 2427 4822 122 33752 15pF 5% NP0 50V
1432 2422 128 02922 SWITCH-TACT 2428 5322 126 11583 10nF 10% X7R 50V
1433 2422 128 02922 SWITCH-TACT 2429 4822 126 13881 470pF 5% 50V
1434 2422 128 02922 SWITCH-TACT 2430 4822 126 13881 470pF 5% 50V
1435 2422 128 02922 SWITCH-TACT 2431 4822 126 13881 470pF 5% 50V
1436 2422 128 02922 SWITCH-TACT 2432 4822 126 13881 470pF 5% 50V
1437 2422 128 02922 SWITCH-TACT 2433 4822 126 13881 470pF 5% 50V
1438 2422 128 02922 SWITCH-TACT 2434 4822 126 13881 470pF 5% 50V
1439 2422 128 02922 SWITCH-TACT 2435 5322 126 11583 10nF 10% X7R 50V
1440 2422 128 02922 SWITCH-TACT 2436 2238 586 59812 100nF +80-20% Y5V 50V
1441 2422 128 02922 SWITCH-TACT 2437 5322 126 11583 10nF 10% X7R 50V
8502 3140 110 22341 CABLE 36P/040/36P 2438 4822 124 12032 4,7µF 20% 50V
2439 2020 552 94427 100
p
F 5% NP0 50V
2440 2020 552 94427 100pF 5% NP0 50V
2441 4822 126 13881 470pF 5% 50V
2442 4822 126 13881 470pF 5% 50V
- CAPACITORS - 2443 2020 552 94427 100pF 5% NP0 50V
2101 2238 586 59812 100nF +80-20% Y5V 50V 2444 4822 126 13881 470pF 5% 50V
2150 5322 126 11578 1nF 10% X7R 50V 2445 5322 126 11583 10nF 10% X7R 50V
2151 5322 126 11578 1nF 10% X7R 50V 2446 5322 126 11583 10nF 10% X7R 50V
2300 4822 124 80483 47µF 20% 6,3V 2447 2238 586 59812 100nF +80-20% Y5V 50V
2301 3198 016 31020 1nF NP0 25V 2448 2238 586 59812 100nF +80-20% Y5V 50V
2302 2238 586 59812 100nF +80-20% Y5V 50V 2449 2238 586 59812 100nF +80-20% Y5V 50V
2303 2238 586 59812 100nF +80-20% Y5V 50V 2450 2238 586 59812 100nF +80-20% Y5V 50V
2400 2238 586 59812 100nF +80-20% Y5V 50V 2451 4822 124 21913 1µF 20% 63V
2401 4822 124 23432 100µF 20% 10V 2452 2238 586 59812 100nF +80-20% Y5V 50V
2402 5322 126 11583 10nF 10% X7R 50V 2453 2238 586 59812 100nF +80-20% Y5V 50V
2403 2020 552 94427 100pF 5% NP0 50V
2404 2020 552 94427 100pF 5% NP0 50V
2405 2020 552 94427 100pF 5% NP0 50V
2406 2020 552 94427 100pF 5% NP0 50V
2407 2238 586 59812 100nF +80-20% Y5V 50V - RESISTORS -
2408 4822 124 23432 100µF 20% 10V 3150 4822 116 52219 330R 5% 0,5W
2409 2238 586 59812 100nF +80-20% Y5V 50V 3151 4822 116 52219 330R 5% 0,5W
2410 5322 126 11583 10nF 10% X7R 50V 3152 4822 116 52219 330R 5% 0,5W
2411 2020 552 94427 100pF 5% NP0 50V 3153 4822 116 52219 330R 5% 0,5W
2412 2020 552 94427 100pF 5% NP0 50V 3154 4822 116 52226 560R 5% 0,5W
2413 2020 552 94427 100pF 5% NP0 50V 3155 4822 116 52226 560R 5% 0,5W
2414 2020 552 94427 100pF 5% NP0 50V 3300 4822 117 11373 100R 1% RC12H
2415 2020 552 94427 100pF 5% NP0 50V 3302 4822 117 12864 82K 5% 0,6W
2416 5322 126 11583 10nF 10% X7R 50V 3303 4822 051 20471 470R 5% 0,1W
2417 4822 126 13883 220pF 5% 50V 3304 4822 051 30103 10K 5% 0,062W
