CONTROLS
8
AZ 1570/ 17 page 8
TOP AND FRONT PANELS
1 DIGITAL EQUALIZER – selects volume or the
various frequencies for adjustment: volume,
bass, mid and high frequencies
2 VOLUME/SOUND CONTROL CENTER –
adjusts the volume level and digital equalizer
settings
3 DIGITAL DBB (Dynamic Bass Boost) –
enhances the bass
4 INCREDIBLE SURROUND – creates a super-
enhanced stereo effect
5 POWER slider – selects the sound source for
CD/ TUNER/ TAPE and also
switches the set off
6 CASSETTE RECORDER keys:
RECORD 0 – starts recording
PLAY 1 – starts playback
SEARCH 5, 6 – fast winds/rewinds the tape
OPEN•STOP /9 – opens the cassette
compartment
– stops the tape;
PAUSE ; – interrupts recording or playback
7 OPEN•CLOSE – opens/ closes the CD door
8 STOP 9 – stops CD playback or erase a CD
program
9 PLAY•PAUSE 2; – starts or interrupts CD
playback
0 BATT LOW – indicates when battery power is
running low
! PROG – CD: programs tracks and reviews the
program;
Tuner: programs preset tuner stations
@ SHUFFLE – plays CD tracks in random order
# SEARCH ∞, §
Tuner: - (down, up) tunes to radio stations;
CD: - searches back and forward within a
track;
- skips to the beginning of a current
track/ previous/ subsequent track
$ REPEAT – repeats a track / CD program /
entire CD
% Display – shows the status of the set
^ BAND – selects waveband
& TUNER PRESET 4, 3 – selects a preset tuner
station (down, up)
BACK PANEL
* p – 3.5 mm headphone jack
( Telescopic antenna – improves FM reception
) AC MAINS – inlet for power cord
¡ Battery door
English
Environmental information
All unnecessary packaging material has been omitted. We have done our utmost to make the
packaging easy to separate into three mono-materials: cardboard (box), expandable polystyrene
(buffer), polyethylene (bags, protective foam).
Your set consists of materials which can be recycled if disassembled by a specialized
company. Please observe the local regulations regarding the disposal of packing
materials, dead batteries and old equipment.
AZ157017 15-12-2000 18:30 Pagina 8
