11
6 Slide the unit into the dashboard until you
hear a click sound.
7 Reconnect the negative terminal of the
car battery.
3 Remove the mounting sleeve with the
supplied disassembly tools.
4 Install the sleeve into the dashboard and
bend the tabs outward to fix the sleeve.
Note
If the unit is not fixed by sleeve but by the •
supplied screws, skip this step.
5 Place the supplied rubber cushion over
the end of the mounting bolt.
183 mm
53.5 mm
English
EN
