Philips CEM200/55 - Electrical Partslist

ELECTRICAL PARTSLIST
MAIN BOARD ASSEMBLY
ANT 996510028982 Antenna Socket
CN5 996510028984 Detachable Connector
D26 996510028974 LED 3.0X1.5MM RED
D27 996510028974 LED 3.0X1.5MM RED
FFC2 996510027733 FFC 7 pin UL20624 P=1.0 L=35
FFC3 996510028977 FFC Cable 24 pin
S1 996510027777 Surface Mount Tact Sw H=5.2
S2 996510027744 Surface Mount Tact Switch 4Pin
S3 996510028986 Push Switch
TU1 996510028975 Tuner Pack KST-C4011LVD-151M
U10 996510028978 IC MCU Supported
U13 996510027763 C L7809CV
U15 996510027776 IC L7805CV
U2 996510027763 IC L7809CV
U3 996510027707 TDA7388
U4 996510027736 IC LM2950L-50
U5 996510027771 IC LS4558F SOP-8 Op
U7 996510027782 IC PLL - DTS LP9257 SOP-20-300-
U8 996510027775 IC 7313
XT3 996510027748 Crystal 32.768 KHz
XT4 996510027774 Crystal 7.2MHz
SERVO BOARD ASSEMBLY
D703 996510027764 Infrared LED BIR-HM133A-TRB
D704 996510027764 Infrared LED BIR-HM133A-TRB
D705
996510027709
Rectifier SMD M7 1 0A/1000V
D705
996510027709
Rectifier SMD M7 1
.
0A/1000V
FFC1 996510028987 FFC 17 Pin UL2896 P=1.0 L=100
SW702 996510027718 Push Switch SW-111
U702 996510027753 IC IS42S16400F-7TL
U707 996510028971 IC S5L8030B
U708 996510027738 IC AP1117 3.3V SOT223-3L
U709 996510027715 IC AP1117-ADJ +/-2%1A
U710 996510027771 IC LS4558F SOP-8 Op
U711 996510027716 IC SA5888
U712 996510027786 IC S29AL004D70TF102
Y701 996510027765 Crystal SMD 16.9344MHz
ACCESSORIES
RC01 996510027724 Remote Control
RU01 996510028991 Rubber End Rubber(Black)
SC01 996510028988 Machine Screw M5x8 Flat
UK01 996510028973 Unit Key1mm EGIW/LOCKER
JI01 996510028983 Standard connector
PL17 996510027794 Panel Front
PL13 996510027735 Trim Plate
9 - 1
