Philips CEM210/98 - Page 12

13
5 Install the sleeve into the dashboard and
EHQGWKHWDEVRXWZDUGWRÀ[WKHVOHHYH
Note
6NLSWKLVVWHSLIWKHXQLWLVQRWÀ[HGE\VOHHYH
but by supplied screws.
6 Place the supplied rubber cushion over
the end of the mounting bolt.
183 mm
53mm
5mm
5mm5mm
2 Remove the two screws on the top of the
unit.
3 Remove the mounting sleeve with the
supplied disassembly tools.
4 Ensure that car dashboard opening is
within these measurements:
English
EN
