ELECTRICAL PARTSLIST - MAIN BOARD (only for -/55
)
- MISCELLANEOUS -
F1 996510002426 CERAMIC FUSE 3.9x10.5mmW
CF1 996510008326 CRYSTAL 12 MHzHC-49/US H=3.5mm
X701 994000004551 CRYSTAL 16.9344MHZ HC-49/US
X1 996510000332 CRYSTAL 32.768KHZ (3x8mm)
X4 994000004451 CRYSTAL 8.000MHZ HC-49/US
DC1 996510002122 DC JACK TC-18-013-03
PH1 996510002121 PHONE JACK 3.6mm TC38-067-05-21
D44 996510002112 RECTIFIER DIODE DL4001-T 1A 50V
D11 994000004363 SMD DIODE SOD80C PMLL4148L
D17 994000004363 SMD DIODE SOD80C PMLL4148L
D2 994000004363 SMD DIODE SOD80C PMLL4148L
D23 994000004363 SMD DIODE SOD80C PMLL4148L
D24 994000004363 SMD DIODE SOD80C PMLL4148L
D26 994000004363 SMD DIODE SOD80C PMLL4148L
D27 994000004363 SMD DIODE SOD80C PMLL4148L
D4 994000004363 SMD DIODE SOD80C PMLL4148L
D402 994000004363 SMD DIODE SOD80C PMLL4148L
D404 994000004363 SMD DIODE SOD80C PMLL4148L
D6 994000004363 SMD DIODE SOD80C PMLL4148L
D7 994000004363 SMD DIODE SOD80C PMLL4148L
D8 994000004363 SMD DIODE SOD80C PMLL4148L
D9 994000004363 SMD DIODE SOD80C PMLL4148L
D3 996510008323 SMD DIODE SS34 DO-214AA
D5 996510008323 SMD DIODE SS34 DO-214AA
ZD1 996510008322
SMD ZENER DIODE BZX384 4.7V
Note: Only these parts mentioned in the list ar
e
normal service parts
.
